ENMG / MOUNTING ACCESSORIES
HS-X35
Die-cast DIN rail mounting clips
Nickel-plated zinc-alloy mounting clips for securing electrical components to 35 mm DIN rail.
Request a quote ↗TECHNICAL DATA / HS-X35
Specifications & selection.
- One-piece die-cast zinc-alloy construction.
- The source identifies nickel plating as the updated finish, replacing the earlier zinc-plated finish.
- For mounting suitable contactors, relays, terminal assemblies and power supplies.
| Model | Clip width | Rail | Material / finish |
|---|---|---|---|
| HS-X35-S | 35 mm | 35 mm DIN rail | Die-cast zinc alloy / nickel plated |
| HS-X35-W | 46.5 mm | 35 mm DIN rail | Die-cast zinc alloy / nickel plated |
Selection & installation notes
- Confirm the equipment mounting-hole pattern, fasteners and clearance against the installation drawing.
- The source does not specify a rated mechanical load, tightening torque or full outline dimensions. Request these values for the proposed assembly before installation.
Based on the official Chinese product page and selection charts ↗. Checked 2026-09-15. Confirm the current specification for the exact model when ordering.
TECHNICAL RESOURCES
Plan your integration.
ENMG electrical accessories — English product-family brochure.
This is a product-family brochure. Request a model-specific datasheet and installation drawing with your inquiry.
