RSA08Y
Eight-position jumper for RSA relay terminals
A molded flat-pin bridge for common-potential linking across matching RSA slim relay terminals.
Request a quote ↗TECHNICAL DATA / RSA08Y
Specifications & selection.
- Eight positions at 6.2 mm pitch.
- Yellow molded insulation.
- Designed for the RSA relay-terminal family.
| Parameter | Published value |
|---|---|
| Model | RSA08Y |
| Structure | Flat-pin molded jumper |
| Positions / pitch | 8 / 6.2 mm |
| Color | Yellow |
| Compatibility | Matching RSA slim relay terminals |
| Current / voltage / thermal limits | Exact RSA08Y assembly specification required |
| Overall dimensions / mass | Not specified in source |
Selection & installation notes
- The shared source table gives 36 A / 250 V for RSLZ2, a different twenty-position RSL bridge. Those ratings do not apply to RSA08Y.
- Shared RSN/RSY/RSK conductor and insulation figures are not RSA08Y test data. Confirm the fitted bridge and socket combination before electrical design.
- Verify the exact RSA socket slot and linked potentials; equal pitch alone does not establish compatibility with another series.
- Check total common current, fully seat all pins with power isolated, and avoid cutting or modifying the jumper. Use the matched accessory and assembly instructions.
Based on the official Chinese product page and selection charts ↗. Checked 2026-09-15. Confirm the current specification for the exact model when ordering.
TECHNICAL RESOURCES
Plan your integration.
ENMG electrical accessories — English product-family brochure.
This is a product-family brochure. Request a model-specific datasheet and installation drawing with your inquiry.
