DIP solid-state relays for interface sockets
Compact potted solid-state relays for compatible G2R/G2RL-format socket or PCB interfaces, with AC, DC and non-polarized output families.
Request a quote ↗TECHNICAL DATA / SSK
Specifications & selection.
- Non-polarized control input.
- 5-pin and 8-pin footprint families.
- TRIAC AC outputs and low-resistance DC options.
| Input | Basic DC | Low-resistance DC | Non-polarized | AC zero-cross | AC random |
|---|---|---|---|---|---|
| 5–24 VDC, code 32 | SSK3D6132 / SSK4D6132 | SSK10D6132 | SSK4K6132 | SSK3A2032 / SSK4A2032 | SSK4A2132 |
| 24 VDC, code 24 | SSK4D6124 | SSK10D6124 | Not listed | SSK4A2024 | SSK4A2124 |
| Suffix | Nominal | Operating range | Approximate impedance |
|---|---|---|---|
| 05 | 5 VDC | 4–6 VDC | 0.5 kΩ |
| 12 | 12 VDC | 9.2–14.4 VDC | 1.5 kΩ |
| 24 | 24 VDC | 19.2–28.8 VDC | 2.2 kΩ; 3.3 kΩ in 4K group |
| 32 | 5–24 VDC | 3–32 VDC | Not stated |
| Parameter | 3A / 4A | 3D / 4D | 10D | 4K |
|---|---|---|---|---|
| Current | 3 / 4 A | 3 / 4 A | 10 A | 4 A |
| Voltage | 75–264 VAC, 45–65 Hz | 5–60 VDC | 0–60 VDC | 0–60 V AC/DC text; AC peak limit applies |
| Non-repetitive surge; duration unspecified | 30 A | 16 A | 180 A | 180 A |
| Peak withstand | 600 V | 60 V | 60 V | 60 V |
| ON voltage | ≤1.2 V at 2 A | ≤1.3 V at 2 A | ≤0.6 V at 10 A | ≤1.2 V at 4 A |
| OFF leakage | ≤3 mA at 240 VAC | ≤1 mA at 60 VDC | ≤1 mA at 60 VDC | ≤0.01 mA at 60 VDC |
| Minimum load | 20 mA | 20 mA | 20 mA | 0.02 mA in source; confirm unit |
| Switching time | ≤half cycle + 1 ms; random turn-on ≤1 ms | ≤1 ms | ≤1 ms | ≤1 ms |
| Parameter | Published specification |
|---|---|
| Input current | Approximately 10 mA, range 5–15 mA |
| Dielectric / insulation | 2500 VAC, 50/60 Hz, 1 minute / ≥1000 MΩ at 500 VDC, input–output |
| Vibration / shock | 10–55 Hz, 0.75 mm double amplitude / 1000 m/s² |
| Operation / storage | −30 to +80 °C / −30 to +100 °C |
| Humidity | 45–85% RH; no condensation or icing |
| Maximum body outline / mass | 29 × 12.7 × 16 mm, excluding pins / approximately 20 g |
| Socket options, 5-pin / 8-pin | RSZE05P / RSZE08P; RS-ZE2M-35M / -48M; G2R-1-SSG / -2-SSG |
Selection & installation notes
- SSK4K AC voltage must stay within the stated 60 V peak limit; 60 VAC RMS must not be inferred. Confirm the exact AC rating and minimum-load unit.
- Footprint similarity does not make a semiconductor output equivalent to changeover mechanical contacts. Verify pinout, output polarity, leakage and the selected socket rating.
- The example photograph shows a different SSK3D6135 input variant (3–36 V). The standard selection table above does not inherit that range.
- Choose suppression and fast protection for the actual load. Derate above 40 °C and for dense mounting; surge figures lack duration. Isolate power before service.
- Source PCB soldering limit: below 260 °C, within 10 seconds. Request the production footprint before board design.
Based on the official Chinese product page and selection charts ↗. Checked 2026-09-15. Confirm the current specification for the exact model when ordering.
TECHNICAL RESOURCES
Plan your integration.
ENMG relays — English product-family brochure.
This is a product-family brochure. Request a model-specific datasheet and installation drawing with your inquiry.
